Spinner Grip Cylinder, Top

25cl25as

3/98

152 Drawings

* These parts available only

in kit #031-24CYL25RK

Item

Part #

Part Name

Piston Seal

Static Seal

Static Seal and Back-up

Rod Seal

Rod W

iper

Piston Nut

Piston

Seal Retainer

Rod Assembly

Barrel Assembly

*

*

*

*

*

031-20008

031-70017

031-25000

031-5A049A

031-2560-BS

1-1

1-2

1-3

1-4

1-5

2

3

4

5

6

2

1

1&1

1

1

4

1

1

1

1

Quantity

Per Unit

Arrow denotes the direction

the seal should face.

Part # 031-25CYL25-AS

Ref. p. 105
