VoIP Engine Configuration
82 Avaya Integrated Management Release 4.0.1 Software Update Manager
Figure 29: VoIP Status Tab - G450
The information in the VoIP Status tab is provided by the VoIP engine and is refreshed
periodically.
The following table lists the fields in the VoIP Status tab and their descriptions.
Table 29: VoIP Status Parameters
Field Description
Slot # The slot in which the VoIP engine resides.
Socket # The socket number of the VoIP engine (relevant only for the
Avaya G450 Device).
Channels in Use The number of channels currently being used.
Total Voice
Channels The total number of voice channels available.
Jitter Buffer size The jitter buffer is a temporary storage area built into the receiver of
each gateway. It uses a mechanism to remove the random delays
between packets, which occur as the packets are routed through the
network.
1 of 2
