Viewing Port Configuration
Issue 5 October 2007 59
Figure 17: Port Configuration Dialog Box - LLDP Tab
The following table provides a list of the fields in the LLDP tab of the Port Configuration dialog
box and their descriptions:
Table 16: Port Configuration Dialog Box - LLDP Tab Parameters
Field Description
LLDP Admin Status The status of LLDP mode on the device. Possible values are:
● Tx Only - LLDP mode is enabled, and is configured to only
accept Tx traffic.
● Rx Only - LLDP mode is enabled, and is configured to only
accept Rx traffic.
● Tx and Rx - LLDP mode is enabled and is configured to
accept both Tx and Rx traffic.
● Disabled - LLDP mode is disabled.
LLDP TLVs Transmission
System Name The system’s network name. When checked, the system advertises
its name to the network.
System Description A brief description of the system (i.e., G250/G350/G450). When
checked, this TLV is advertised.
System Capabilities A brief description of the system’s capabilities. When checked, this
TLV is advertised.
Port Description A brief description of the device port. When checked, this TLV is
advertised.
1 of 2
