WAN Configuration
106 Avaya Integrated Management Release 4.0.1 Software Update Manager
Figure 38: Channel Group Dialog Box- Channel Group Tab
The following table provides a list of the fields in the Channel Group tab of the Channel Group
dialog box and their descriptions:
Table 39: Channel Group Dialog Box - Channel Group Parameters
Field Description
Description A description of the PPP session.
Port Type The port type.
Port Functionality The framing mode of the port. Possible modes are:
● ds0 bundle
● Unframed E1 (for E1 ports only)
Encapsulation The encapsulation method for the PPP session. Possible
encapsulation types are:
● PPP
● Frame Relay
● Frame Relay Non IETF (for the MM340 Media Module)
1 of 2
