Chapter 9: VLANs
This chapter provides the information and instructions you need to use VLANs. It includes the
following sections:
●
- An overview of VLANs and their components.
●
- Instructions on how to access the VLAN Configuration dialog box and
a description of the VLAN Configuration dialog box.
●
- Instructions on how to create, delete, and rename VLANs.
●
- Instructions on how to view VLAN settings for ports on the
device.
●
- Instructions on how to configure VLAN settings for ports
on the device.
●
- Instructions on how to update the device with new VLAN
information.
VLAN Configuration Overview
This section contains an overview of VLANs and how to configure them, and contains the
following sections:
●
- A brief description of VLANs and their functions.
●
- A brief description of the Master VLAN List and it’s functions.
●
- A brief description of VLAN tags and their functions.
VLANs Overview
The building blocks of VLANs are switch ports. To build a new VLAN you need to define a VLAN
name and number. You can then add switch ports to the VLAN by configuring the PVID of the
port to the VLAN number. The ports are members of the VLAN whose number is their PVID. In
addition, you can configure the VLAN tagging mode and binding style of the switch ports.
VLAN #1 is the default VLAN and is named Default.
For more information about VLANs, refer to VLANs in the Network Protocols section of The
Reference Guide.
