Using the Table View
Issue 5 October 2007 261
● Copying Rules
● Moving Rules
● Deleting Rules
To view the Rules list, select the policy in the Tree View whose rules you wish to view, and then
select the Policy Based Routing Rules tab in the Table View. If the Rules list is not in the
active policy, the Rules list opens in the Table View.
If the selected Policy Based Routing Rules list is in the active policy, the Policy Based Routing
Rules list appears as Read-only. To edit an active Rules list, activate a different policy on that
interface and direction, and deactivate the policy with the Rules list you wish to edit.
Figure 121: Policy Based Routing Rules List
The following table lists the fields in the Rules list and their descriptions:
Table 94: Policy Based Routing Rules List Fields
Field Description
ID Index number of the rule in the Policy Based Routing Rules List.
Description Description of the rule. You cannot configure this field for default rules.
Not Logical not. The rule is disabled and bypassed.
Src IP Address Source Address. The source address of the packet being matched by the
rule.
Src Wildcard Source Address Wildcard. A wildcard that can modify the definition of the
specified source address.
You can change the Source Address Wildcard by using the pull-down list
or entering a user defined wildcard. Possible SrcAddWild values include:
● Host
● Any
● User Defined
For more information about using wildcards, refer to “Using Address
Wildcards” on page 272 .
Not Logical not. This enables all addresses except for the address listed in
the following Dst IP Address field.
Dst IP Address Destination Address. The destination address of the packets matched by
this rule.
1 of 3
