Applications Editor Tool
278 Avaya Integrated Management Release 4.0.1 Software Update Manager
To open the Applications Editor:
Select Tools > Applications Editor. The Applications Editor opens.
Figure 127: Applications Editor
The following table provides a list of the fields in the Application Editor and a description of each
field:
Table 100: Applications Editor Fields
Field Description
Name The name of the application protocol.
Type The application type. Possible types are:
● TCP
● UDP
● * (Other protocols)
Min Port The low end of the range of ports for this protocol.
Max Port The high end of the range of ports for this protocol.
Notes A user defined description of the protocol.
