Avaya Media Gateway G250 - Manual (Page 103)

Ethernet WAN Port Configuration
Issue 5 October 2007 103
Ethernet WAN Port Configuration - Extended Keep Alive Tab
The Extended Keep Alive tab of the Ethernet WAN Port Configuration dialog box enables you to
set parameters for the Extended Keep Alive functionality of the Avaya G250/G350/G450
Device. Extended Keep Alive allows you to precisely tune network keep alive traffic to gain an
accurate representation of your network’s connection status.
Figure 37: Ethernet WAN Port Configuration Dialog Box - Extended Keep Alive Tab
The following table lists the fields in the Ethernet LAN Port Configuration - Extended Keep Alive
tab, and their descriptions:
Table 38: Ethernet LAN Port Configuration - Advanced Tab
Field Description
Keep Alive ICMP
Mode The keepalive operation mode. Possible values are:
● Enable
● Disable
1 of 2
