7.5 Removing the Magazine
If the film has not run through the camera completely:
• Open the camera door.
• Open the movement by turning the inching knob
➪
photo until the mark aligns with the mark on the
movement and then turn the movement locking lever
➪
photo towards the „OPEN“ position.
• Pull out the film loop sideways from between the
movement block and the film gate.
• Bring the loop into the area between the movement
block and the magazine throat assembly.
Ensure that the loop does not get twisted behind
the movement block as otherwise the film could
be damaged when removing the magazine!
• Swing the movement block forwards again and lock.
• Hold the magazine firmly with one hand and pull the
magazine locking lever back with the other.
When pulling away the magazine ensure that
the film does not get damaged!
• Pull the magazine off upwards.
• Replace the cover on the camera opening.
If the entire film has run through the camera:
• Hold the magazine firmly with one hand and pull the
magazine release lever back with the other.
• Pull the magazine off upwards.
• Replace the cover on the camera opening.
Camera Body
