Work Light WL-3

• Screw the dovetail-adapter to the handgrip.

• Slide the work light into the dovetail-guide and clamp.

• Connect the plug to the “RS”-socket.

• By adjusting the flexible arm, bring the work light into

the desired position. The work light can be turned on

and off with the ring on the lamp head


. The

brightness of the work light can be adjusted with the

mechanical aperture.

Heated Eyecup HE-4

The heated eyecup prevents the eyepiece


from

fogging in low temperatures e.g. when filming outdoors

in winter.

• Pull the normal eyecup off the eyepiece, then place the

heated eyecup on the eyepiece.

• Plug the heated eyecup with cable KC-42S to the RS-

socket.

• Set the heating level with the toggle switch


:

“LO”: low heat output

“HI”: higher heat output.

If the camera and accessories are powered by

battery, it is recommended to switch off the

eyecup-heating during extended breaks in

filming.

HE-4

WL-3

Accessories
