Activate Format Markings
If the electronic format markings are not parallel to the
ground glass format markings, readjust the CCD chip with
the alignment screw, as shown in chapter 10.3.3 Alignment
of the image position (X-, Y- and Rotation) and focus
Note: Only active frame lines can be positioned. If no
frame line is on (FORMAT OFF), no position line
can be reached with the cursor >. If Format 1
is on, only – POSITION 1 can be reached with
the cursor >. Only if format 1 & 2 is selected,
all - POSITION lines can be used.
It is possible to have no format marking (OFF), format marking
number one (1), format-marking number two (2) or both
format markings at the same time (1 & 2) on display.
• Move the cursor > with the keys Ê and Ë to the line
– FORMAT. Pressing the key Í will switch from OFF to
1 to 2 to 1 & 2 and back to OFF, the key Ì will switch
in the opposite direction.
MENU FORMAT MARKING
-> - FORMAT 1
- POSITION 1 Ö
- POSITION 1 Ü
POSITION 2 Ö
POSITION 2 Ü
- WHITE LEVEL 2
- OUTSIDE LIGHT
- EXIT
Video-Assist-System
