12. Super 35
When delivered, the camera is set to Super 35.
The Super 35 format offers a range of technical
advantages compared to filming with anamorphic lenses:
• a larger selection of available focal lengths,
• smaller and lighter-weight lenses,
• faster lenses,
• shorter lens focus for close-up shots,
• clearly reduced image distortion and geometric aberrations.
In addition, a greater variety of post-production
possibilities is available.
For shooting in Normal 35, the lens mount receptacle and
the upper plate of the bridge plate must be altered for the
format. This ensures that the lenses and accessories are
exactly aligned to the optical center of Normal 35.
Converting the Lens Mount
Receptacle to Normal 35
For shooting in Normal 35, the lens mount receptacle
must be turned 180°.
• Remove the six cylindrical screws ➪ photo .
• Unscrew both locking grips ➪ photo .
• Turn the lens mount receptacle so that the number “1”
is positioned next to the marking ➪
photo .
• Unscrew the index pin ➪ photo and screw into the
opposite inner thread.
• Screw both locking grips firmly into the correct
operating position ➪
photo .
• Replace the six cylindrical screws and screw tight.
• Check the flange focal distance.
cylindrical screws locking grips
index pin marking
Super 35
