Administering the Switch
46 Installation Guide
9. Follow Steps a through i to add an ASAI-enabled station. Completing the LINK screen
administers an adjunct IP link between DEFINITY and a Avaya Computer Telephony
server.
a. In the
Extension:
type any valid extension on the dial plan (for example,
1008
).
b. In the
Type:
field, type
ADJLK
c. In the
Port:
field, type an available port number
d. In the
Name:
field, type the name of the Avaya Computer Telephony server
e. In the
XID
: field, accept the default (
n
)
f. In the
Fixed TEI:
field,
type y
g. In the
MIM Support:
field, accept the default (
n)
h. In the
CRV Length:
field,
type
2
i. In the
Event Minimization:
field, accept the default (
n)
All other fields on the Link screen use the default values.
This completes Task 1: DEFINITY Administration. Proceed to
