Pre-Release 11 Link Administration Instructions
230 Installation Guide
Task 2: DLG Administration
The objective of Task 2 is to establish connectivity between DEFINITY and your Avaya CT
server, by way of the DLG. Task 2 assumes that the DLG is already installed and
administered. For more information see DEFINITY ECS and CallVisor ASAI Applications
over MAPD (555-230-136).
From the MAPD administrative terminal, follow these steps to complete Task 2.
1. Log in to the MAPD system
The Main Menu appears.
2. From the Main Menu, select 2. TCP/IP Administration .
Main Menu
This line is used to provide abbreviated help on the currently selected field.
ENTER EXIT REFRESH HELP
1. Login/Password Administration
2. TCP/IP Administration...
3. Port Administration...
4. Maintenance...
5. DLG Port Status/Control
6. CV/LAN Port Status/Control
7. Exit
Main Menu
This line is used to provide abbreviated help on the currently selected field.
ENTER EXIT REFRESH HELP
1. Login/Password Administration
2. TCP/IP Administration...
3. DLG Administration
4. Maintenance...
5. DLG Port Status/Control
6. Exit
If both the DLG and CVLAN
applications are on the MAPD
this Main Menu appears.
3. Port Administration. .. is
for access to DLG and CVLAN.
If only the DLG application
is on the MAPD
this Main Menu appears.
3.DLG Administration
for access to DLG.
