DEFINITY ECS and DEFINITY PROLOGIX Administration
Issue 1 October 2003
229
Note:
Note:
For newer versions of the switch, the STATION screen may contain more
options. Only the options in Steps a through i are relevant to Avaya CT.
9. Follow Steps a through i to add an ASAI-enabled station. Completing the STATION
screen administers an adjunct IP link between DEFINITY and a Avaya CT server.
a. In the
Extension:
type any valid extension on the dial plan (for example,
1008
).
b. In the
Type:
field, type
ADJLK
c. In the
Port:
field, type an available port number
d. In the
Name:
field, type the name of the Avaya CT server
e. In the
XID
: field, accept the default (
n
)
f. In the
Fixed TEI:
field, type
y
g. In the
MIM Support:
field, accept the default (
n
)
h. In the
CRV Length:
field, type
2
i. In the
Event Minimization:
field, accept the default (
n
)
All other fields on the Station screen use the default values.
This completes Task 1: DEFINITY Administration. Proceed to
STATION
Extension: 1008
add station 1008
Page 1 of 2 SPE A
-----------------------------------------------------------------------------
-----------------------------------------------------------------------------
Type: ADJLK___
Port: 1a0602___
Name: ____________________
TN: 1__
COR: 1_
COS: 1_
STATION OPTIONS
BRI OPTIONS
XID? n
MIM Support? n
Fixed TEI? y
CRV Length: 2
Hunt-to Station: _____
TEI: 1_
