Issue 1 October 2003 223
Appendix D: Pre-Release 11 Link
Administration Instructions
The following instructions apply to a Release 10 or earlier switch.
Introduction
This appendix describes DEFINITY-based tasks that must be performed to implement
communications between the DEFINITY switch and the Avaya Computer Telephony
server.
Scope of this appendix
Refer to Figure D-1 as you read this section. The scope of this appendix includes the
DEFINITY switch and the communications interface to the Avaya CT server. The affected
components are as follows.
● The DEFINITY switch (DEFINITY ECS, DEFINITY PROLOGIX, or DEFINTY ONE)
● DEFINITY LAN Gateway (DLG) on either a Multi-Application Platform for DEFINITY
(MAPD) or a DEFINITY ONE.
Note:
Note:
Hardware Platforms that accommodate the DLG software are:
- TN800 series MAPD, which is used in a DEFINITY ECS or DEFINITY
PROLOGIX.
- TN795 Processor Card (PROCR), which is used in the DEFINITY ONE. The
PROCR accommodates the DLG. Also, in some configurations, the TN795
card (with DLG resident) relies on the TN799 Control LAN (C-LAN) card for
LAN isolation.
