OmniConnect / ISDN User’s Manual Page 58
Part number 613-10787-00
6.3.12. DHCP server reserve/free IP address
The DHCP Server Reserve/Free IP Address screen allows reserving or freeing an IP address
from the DHCP Server IP addresses table. The DHCP Address Table displays the current
status of all the IP addresses managed by the DHCP server. This screen allows reserving an IP
address from the DHCP server IP address range for a client or a server who must have a fixed
IP address. The Ethernet MAC address of the computer for which the IP address is being
reserved must be known. Enter the IP address and the MAC address for reserving that IP
address in the boxes provided. The MAC address must be entered in IEEE LSB format, with
the I/G bit entered in the first box. The IP address may be freed if the address was previously
reserved using the Reserve IP Address check box. Enter the IP address that is to be freed and
click the Next button to free that IP address.
