Allied Telesis AT-S31 - Manual (Page 62)

Supported PowerBlade Modules
62
Table 5 AT-PB300 Series Media Converters
Note 1: Maximum distance can only be obtained when the UTP/STP cabling is installed and verified to
TIA/EIA 568A Commercial Building Telecommunications Cabling Standard.
Note 2: Maximum distance for 100 Mbps Optical Datalinks are dependent on the following factors:
type of optical fiber, duplex mode of both end-nodes, and maximum optical loss budget for
each of the optical fiber at the operating optical wavelength.
Table 6 AT-PB1000 Series Media Converters
Model
100Base-FX Port 100Base-T Port
Connector
Maximum
Distance
Connector
Maximum
Distance
AT-PB301 VF-45
2 km
(1.2 mi)
RJ-45
100 m
(328 ft)
AT-PB302 MT-RJ
2 km
(1.2 mi)
RJ-45
100 m
(328 ft)
AT-PB303 LC
2 km
(1.2 mi)
RJ-45
100 m
(328 ft)
AT-PB304 FJ
2 km
(1.2 mi)
RJ-45
100 m
(328 ft)
Model
1000Base-LX 1000Base-SX
Connector
Maximum
Distance
1
1. Assumes 10/125 micron single-mode fiber optic cable.
Connector
Maximum
Distance
2
2. Assumes 50/125 micron multimode fiber optic cable.
AT-PB1001/1 SC
10 km
(6.2 mi)
SC
550 m
(1,804 ft)
AT-PB1001/2 SC
20 km
(12.4 mi)
SC
550 m
(1,804 ft)
AT-PB1001/3 SC
50 km
(31 mi)
SC
550 m
(1,804 ft)
AT-PB1001/4 SC
70 km
(43.4 mi)
SC
550 m
(1,804 ft)
