Managing the Chassis
30
To run the diagnostic tests, perform the following procedure:
1. From the Main Menu, select Administration.
The Administration Menu is displayed.
2. Select Diagnostics.
The diagnostic tests take only a few seconds to complete. The results
are displayed in a Diagnostics screen, as shown below.
The Flash PROM, RAM, and Serial Interface test results are displayed as
Good or Failed. If the chassis does not have a optional power supply
installed, the results for “Power module B” and “Fan B” are displayed
as Failed.
3. Return to the Main Menu.
Administration Menu
Update software in another system
Broadcast updated software to all systems
XModem software updated to this system
Connect to a remote system
Ping a remote system
Activity monitor
Diagnostics
Reset and restart the system
Return to Main Menu...
Allied Telesyn PowerBlade PBC18
MAC Address 00A0DS xxxxxx
AT-PBM02 Management Module Software: Version 1.0.1
Running x days, xx minutes, xx seconds
Current Time: 07/10/2000 15:27:30
Diagnostic Results:
Flash PROM Good System 3.3V power: +3.30V
RAM Good System 5V power: +4.94V
Serial interface Good System 3V battery: +2.95V
Power module A Good Temperature (MGMT Module): +31.5C
Power module B Good Temperature (Chassis): +28.5C
Fan #1 Good Fan Speed #1: +4115rpm
Fan #2 Good Fan Speed #2: +4185rpm
Fan #3 Good Fan Speed #3: +2650rpm
Return to Administration Menu...
