59
$SSHQGL[ %
6XSSRUWHG 3RZHU%ODGH 0RGXOHV
The following tables list the PowerBlade Media Converters and Switches
that are supported by the AT-S31 Version 1.0 software.
Table 2 AT-PB10 Series Media Converters
Model
10Base-FL Port 10Base-T Port
Connector
Maximum
Distance
1
1. Maximum distance may be less depending on the duplex mode of the end stations and the type of
fiber optic cabling used with the port.
Connector
Maximum
Distance
1
AT-PB13 ST 2 km (1.2 mi) RJ-45 100 m (328 ft)
AT-PB14 SC 2 km (1.2 mi) RJ-45 100 m (328 ft)
Model
Port 1 Port 2
Connector
Maximum
Distance
Connector
Maximum
Distance
2
2. Maximum distance can only be obtained when the UTP/STP cabling is installed and verified to
TIA/EIA 568A Commercial Building Telecommunications Cabling Standard.
AT-PB15 RJ-45
100 m
(328 ft)
BNC 185 m (606 ft)
