AT-S31 Version 1.0.1 User’s Guide
17
The Main Menu is displayed.
8VLQJ WKH
7HUPLQDO
,QWHUIDFH
If you are using a DEC VT100 or ANSI (the default) terminal configuration,
refer to the table below for instructions on how to move through the
menus and select menu options.
Enabled options in menus are preceded with a > symbol. In the
following example, the first option is enabled:
> Enable this port
Disable this port
When you press to select a field in which you can enter a value,
the -> symbol is displayed. For example:
System name: ->
Allied Telesyn AT-PBM02 Management Module: 1.0.1
Main Menu
Module status and configuration
Administration
System Configuration
Quit
When directed to You must
Select an option Highlight the option by pressing the Up (
↑
)
or Down (
↓
) arrow key; then press
or
Type the first character of the desired option
at the prompt and press .
If two or more options have matching initial
characters, type the initial characters until the
option you want is highlighted; then press
.
Enter information (for
example, the IP
address of a switch) Type the information and press .
Return to the previous
screen Select the “Return” option at the bottom of
the menu or Press .
