Managing the Modules
42
&RQILJXULQJ WKH 3RUW 3DUDPHWHUV
To change the parameters of the ports on a specific module, perform the
following procedure:
1. From the Main Menu, select Module status and configuration.
The Chassis Status Menu is displayed.
2. Use the arrow keys on the keyboard to highlight a module on which
you want to configure the ports.
3. Press .
The Module Configuration Menu is displayed.
4. Use the arrow keys to select the port that you want to configure.
5. Press .
An example of a Port Configuration Menu is shown below.
6. Make the necessary changes. Changes are immediately activated on
the port.
Mode options under the Port Configuration Menu will vary
depending on the type of PowerBlade module you are viewing. The
options are:
Link State
This selection indicates whether there is an active connections
between a port and the device connected to the port. Online
indicates that there is a link while Offline indicates that there is no link.
RX/ACT
The module is either receiving (RX) data or activity (ACT) has been
detected on the port.
Port Configuration Menu
Module 3 - Port B(100BaseTX)
Link State: Online
RX/ACT: On
>Full duplex
Half duplex
Return to Module Configuration Menu...
