Getting Started
16
6WDUWLQJ D /RFDO 2PHJD 6HVVLRQ
You can access the Omega management interface through the RS-232
port on the AT-PBM02 management module. This creates a Local Omega
session.
To start a Local Omega session, perform the following procedure:
1. Connect one end of a straight-through RS-232 cable with a DB9
connector to the RS-232 port on the management module and the
other end of the cable to a terminal or PC with a terminal emulation
program.
2. Configure the terminal or terminal emulation program as follows:
❑ Type of terminal: VT100-compatible/ANSI
❑ Baud rate: 9600
❑ Data bits: 8
❑ Parity: None
❑ Stop bits: 1
❑ Flow control: None
Note
The default settings for the Omega’s terminal interface are for a DEC
VT100 or ANSI terminal, or an equivalent terminal emulation
program. Once you have started an Omega session, you can change
some of these values. For instructions, refer to the section
3. Press the
4. If prompted for a password, enter the password for the Omega
interface. The default is no password. You can later configure a
password. For instructions, refer to
