Getting Started
22
Table 1 lists the menu options.
Table 1 Omega Main Menu Selections
Menu Selection Page Function
Module Status and
Configuration 38 , 39 Displays the status of the modules and ports. Also
used to assign names to the modules and configure
the port settings.
Administration
Update software in
another system 55 Downloads the AT-S31 software from one
management module to another management
module.
Broadcast updated
software to all systems 56 Downloads the AT-S31 software from one
management module to all management modules
on the network.
XModem software
updated to this system 53 Downloads the AT-S31 software to the
management module using XModem. This option is
only available through a local session.
Connect to a remote
system 35 Enables you to connect to and manage another
PowerBlade PBC18 while running a local
management session on a chassis.
Ping a remote system 32 Tests the connectivity to a network end-node.
Activity monitor 31 Displays a screen listing the activity for the chassis.
Diagnostics 29 Performs a series of diagnostic tests on the chassis.
Reset and restart the
system 33 Resets the management module.
System Configuration
Omega options 46 , 48 , 49 Configures the Omega security features, such as,
the Omega password and the timeout value.
IP parameters 24 Configures the IP parameters for the chassis, such as
the IP address, subnet mask, and gateway address.
Also used to specify the IP addresses of up to four
network management stations to receive traps from
the chassis.
Terminal configuration 34 Adjusts the settings for the RS-232 port.
