The user may set the following parameters:
Parameter Description
Unit Choose the switch in the switch stack to be configured by using the pull-down menu.
From/To A consecutive group of ports may be configured starting with the selected port.
Mode Active – Active LACP ports are capable of processing and sending LACP control frames.This allows LACP
compliant devices to negotiate the aggregated link so the group may be changed dynamically as needs require.
In order to utilize the ability to change an aggregated port group, that is, to add or subtract ports from the
group, at least one of the participating devices must designate LACP ports as active. Both devices must support
LACP.
Passive – LACP ports that are designated as passive cannot initially send LACP control frames. In order to allow
the linked port group to negotiate adjustments and make changes dynamically, one end of the connection must
have "active" LACP ports (see above).
After setting the previous parameters, click Apply to allow your changes to be implemented.The LACP Port Table shows which ports are active and/or
passive.
6-9 MAC Notification
MAC Notification is used to monitor MAC addresses learned and entered into the forwarding database.
MAC Notification Global Settings
To globally set MAC notification on the Switch, open the following screen by opening the MAC Notification folder and clicking the MAC Notification
Global Settings link:
Figure 6- 13. Current and New MAC Notification Global Settings window
The following parameters may be modified:
Parameter Description
State Enable or disable MAC notification globally on the Switch.The default setting is Disabled.
Interval (sec) The user may set the time, between 1 and 2,147,483,647 seconds, between MAC notifications.The default
setting is 1 second.
History size The maximum number of entries listed in the history log used for notification. Up to 500 entries can be
specified.The default setting is 1.
Current MAC notification configurations can be viewed in the Current MAC Notification Global Settings window, as seen above.
