To display the detailed entry for a given user, click on the hyperlinked User Name.This will open the SNMP User Table Display page, as shown below.
Figure 8- 2. SNMP User Table Display window
The following parameters are displayed:
Parameter Description
User Name An alphanumeric string of up to 32 characters.This is used to identify the SNMP users.
Group Name This name is used to specify the SNMP group created can request SNMP messages.
SNMP Version V1 – Indicates that SNMP version 1 is in use.
V2 – Indicates that SNMP version 2 is in use.
V3 – Indicates that SNMP version 3 is in use.
Auth-Protocol None – Indicates that no authorization protocol is in use.
MD5 – Indicates that the HMAC-MD5-96 authentication level will be used.
SHA – Indicates that the HMAC-SHA authentication protocol will be used.
Priv-Protocol None – Indicates that no authorization protocol is in use.
DES – Indicates that DES 56-bit encryption is in use based on the CBC-DES (DES-56) standard.
To return to the SNMP User Table, click the Show All SNMP User Table Entries link.
To add a new entry to the SNMP User Table Configuration, click on the Add button on the SNMP User Table page.
This will open the SNMP User Table Configuration page, as shown below.
Figure 8- 3. SNMP User Table Configuration window
The following parameters can be set:
