Figure 8- 5. SNMP View Table Configuration window
The SNMP Group created with this table maps SNMP users (identified in the SNMP User Table) to the views created in the previous menu.
The following parameters can be set:
Parameter Description
View Name Type an alphanumeric string of up to 32 characters.This is used to identify the new SNMP view being created.
Subtree OID Type the Object Identifier (OID) Subtree for the view.The OID identifies an object tree (MIB tree) that will be
included or excluded from access by an SNMP manager.
View Type Select Included to include this object in the list of objects that an SNMP manager can access. Select Excluded to
exclude this object from the list of objects that an SNMP manager can access.
To implement your new settings, click Apply.To return to the SNMP View Table, click the Show All SNMP View Table Entries link.
SNMP Group Table
An SNMP Group created with this table maps SNMP users (identified in the SNMP User Table) to the views created in the previous menu.To view the SNMP
Group Table, open the SNMP Manager folder and click the SNMP Group Table entry.The following screen should appear:
Figure 8- 6. SNMP Group Table
To delete an existing SNMP Group Table entry, click the corresponding under the Delete heading.
To display the current settings for an existing SNMP Group Table entry, click the hyperlink for the entry under the Group Name.
To add a new entry to the Switch's SNMP Group Table, click the Add button in the upper left-hand corner of the SNMP Group Table page.This will
open the SNMP Group Table Configuration page, as shown below.
152 Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch
