AT-S63 Management Software Menus Interface User’s Guide
Section VIII: Management Security 857
Displaying the ACEs
To display the ACEs in the management ACL, perform the following
procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 54.
2. From the System Administration menu, type 7 to select Management
ACL.
The Management ACL Configuration menu is shown in Figure 288 on
page 850.
3. From the Management ACL Configuration menu, type 5 to select
Display All Management ACL Entries.
The Display All Management ACL Entries menu is shown in
Figure 290.
Figure 290. Display All Management ACL Entries Menu
The menu provides the following information about the ACEs:
ID
The entry’s identification number.
IP Address
The IP address of a management station or a subnet.
Mask
The parts of the IP address the switch is filtering on.
Application
The application that the management station is permitted to use to
manage the switch. The options are Telnet, Web, Ping and All.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Display All Management ACL Entries
ID IP Address Mask Application
------------------------------------------------------
1
133.22.145.18 255.255.255.255 All
2 133.22.146.0 255.255.255.0 Web
U - Update display
R - Return to Previous Menu
Enter your selection?
