AT-S63 Management Software Menus Interface User’s Guide
Section VI: VLANs 617
Modifying a Port-based or Tagged VLAN
Note
To modify a VLAN, you need to know its VID. To view VLAN VIDs,
refer to “Displaying VLANs” on page 621.
To modify a VLAN, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 206 on page 610.
2. From the VLAN Configuration menu, type 4 to select Configure
VLANs.
The Configure VLANs menu is shown in Figure 207 on page 611.
Note
If selection 4, Configure VLANs, is not displayed in the menu, the
switch is running a multiple VLAN mode. To change a switch’s VLAN
mode, refer to “Selecting a VLAN Mode” on page 666.
3. From the Configure VLANs menu, type 2 to select Modify VLAN.
The Modify VLAN menu is shown in Figure 209.
Figure 209. Modify VLAN Menu
Note
Selection 2, Change GARP VLAN, is described in Chapter 26,
“GARP VLAN Registration Protocol” on page 633. Selection 3,
Change MAC Associations, is explained in Chapter 29, “MAC
Address-based VLANs” on page 685.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Modify VLAN
1 - VLAN ID (VID) ........
2 - Change GARP VLAN
3 - Change MAC Associations
R - Return to Previous Menu
Enter your selection?
