Page 658
Chapter 26: GARP VLAN Registration Protocol
658
Section VI: VLANs
The GVRP State Machine menu (page 2) is displayed, as shown in
Figure 228.
Figure 228. Display GVRP State Machine Menu (page 2)
The information in the menu is defined in Table 22. This information is
for viewing purposes only.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager
11:20:02 02-Mar-2005
GVRP State Machine
State Machine for VLAN: 1
Port
App
Reg | Port App Reg
| Port App
Reg | Port App Reg |
------------------------------------------------------------------
1
Aa
Fix | 2
Aa
Fix
| 3
Vo
Mt
| 4
Vo
Fix |
5
VO
Fix | 6
Vo
Fix
| 7
VO
Mt
| 8
Vo
Fix |
9
Vo
Fix | 10
Vo
Fix
| 11
Vo
Mt
| 12
Vo
Fix |
13
Vo
Fix | 14
Vo
Fix
| 15
Vo
Mt
| 16
Vo
Fix |
17
Aa
Fix | 18
Vo
Fix
| 19
Vo
Mt
| 20
Vo
Fix |
21
Vo
Mt
| 22
Vo
Mt
| 23
Aa
FIx | 24
Aa
Fix |
-----------------------------------------------------------------
U - Update Display
R - Return to Previous Menu
Enter your selection?
Table 22. GVRP State Machine Parameters
Parameter
Meaning
Port
Port number on the switch; this port belongs to
the GARP application. If the GARP application
has no ports, “No ports have been assigned” is
displayed.
