Chapter 8: Static and LACP Port Trunks
172 Section I: Basic Features
The Modify LACP (IEEE 8023ad) Aggregator menu is shown in Figure
48.
Figure 48. Modify LACP (IEEE 8023ad) Aggregator Menu
5. Type 1 to select Aggregator and, when prompted, enter the name of
the aggregator to be modified. The name is case-sensitive. (To display
the names of the aggregators on a switch, refer to “Displaying LACP
Port and Aggregator Status” on page 174)
After you enter the aggregator’s name, the specifications of the
aggregator are displayed in the menu.
6. Configure the following parameters as necessary:
Note
You cannot modify the name or adminkey of an aggregator. If you
need to change an aggregator’s name or adminkey, you must delete
the aggregator and recreate it.
3 - Distribution Mode
Sets the load distribution method. Possible settings are:
ˆ SRC MAC - Source MAC address
ˆ DST MAC - Destination MAC address
ˆ SRC/DST MAC - Source address /destination MAC address
ˆ SRC IP - Source IP address trunking
ˆ DST IP - Destination IP address trunking
ˆ SRC/DST IP - Source address /destination IP address
The default is SRC/DST MAC. For background information, refer to
“Load Distribution Methods” on page 156.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Modify LACP (IEEE 802.3ad) Aggregator
1 - Aggregator ..................
2 - Adminkey .................... 0x0000
3 - Distribution Mode ........... SRC/DST MAC
4 - Port Range ..................
M - Modify Aggregator
R - Return to Previous Menu
Enter your selection?
