AT-S63 Management Software Menus Interface User’s Guide
Section VI: VLANs 655
Displaying the GIP Connected Ports Ring
To display the GIP connected ports ring, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 206 on page 610.
2. From the VLAN Configuration menu, type 8 to select Configure GARP-
GVRP.
The GARP-GVRP menu is shown in Figure 218 on page 642.
3. From the GARP-GVRP menu, type O to select Other GVRP
Parameters menu.
The Other GARP Parameters menu is shown in Figure 222 on page
648.
4. From the Other GARP Port Parameters menu, type 3 to select Display
GIP Connected Ports Ring.
The GIP Connected Ports Ring menu is shown in Figure 226.
Figure 226. GIP Connected Ports Ring Menu
The GIP Connected Ports Ring menu displays the following
information:
GARP Application
Identifies the GARP application, that is, “GVRP.”
GIP Context ID
A number assigned to the instance for the GIP context.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
GIP Connected Ports Ring
GARP Application: GVRP
GIP Context ID: 0, STP ID: 0
------------------------------------------------------
4 -> 12 -> 18
U - Update Display
R - Return to Previous Menu
Enter your selection?
