Figure 185: display rstp port configuration menu – Allied Telesis AT-S63 User Manual
Page 549
AT-S63 Management Software Menus Interface User’s Guide
Section V: Spanning Tree Protocols
549
3. From the RSTP menu, type P to select RSTP Port Parameters.
The RSTP Port Parameters menu is shown in Figure 183 on page 547.
4. From the RSTP Port Parameters menu, type 2 to select Display RSTP
Port Configuration.
The Display RSTP Port Configuration menu is shown in Figure 185.
Figure 185. Display RSTP Port Configuration Menu
The Display RSTP Port Configuration menu displays a table that
contains the following columns of information:
Port
The port number.
Edge-Port
Whether or not the port is operating as an edge port. The possible
settings are Yes and No.
Point-to-Point
Whether or not the port is functioning as a point-to-point port. The
possible settings are Yes, No, and Auto Detect.
Cost
Port cost of the port. The default is Auto Update.
Priority
The number used as a tie breaker when two or more ports have equal
costs to the root bridge.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager
11:20:02 02-Mar-2005
Display RSTP Port Configuration
Port | Edge-Port |Point-to-Point |
Cost
|
Priority
--------------------------------------------------------------
1
Yes
Auto Detect
Auto Update
128
2
Yes
Auto Detect
Auto Update
128
3
Yes
Auto Detect
Auto Update
128
4
Yes
Auto Detect
Auto Update
128
5
Yes
Auto Detect
Auto Update
128
6
Yes
Auto Detect
Auto Update
128
7
Yes
Auto Detect
Auto Update
128
8
Yes
Auto Detect
Auto Update
128
1
Yes
Auto Detect
Auto Update
128
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
