AT-S63 Management Software Menus Interface User’s Guide
Section I: Basic Features 161
SRC MAC Source MAC address.
DST MAC Destination MAC address.
SRC/DST MAC Source address/destination MAC address.
SRC IP Source IP address.
DST IP Destination IP address.
SRC/DST IP Source address/destination IP address.
ˆ Status - The operating status of the trunk. If the trunk has
established a link with the other device, status will be UP. If the
trunk has not establish a link or the ports in the trunk are disabled,
status will be DOWN.
4. To create a new trunk, type C to select Create Trunk.
The Create Trunk menu is shown in Figure 44.
Figure 44. Create Trunk Menu
5. Configure the following parameters as necessary:
1 - Trunk ID
Specifies the trunk ID, a value from 1 to 6. You cannot specify a trunk
ID. The management software selects it for you. The default value is
the next unused ID number.
2 - Trunk Name
Specifies the trunk name. Enter a name for the trunk. The name can be
up to 16 alphanumeric characters. No spaces or special characters,
such as asterisks and exclamation points, are allowed. Each trunk
must have a unique name.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Create Trunk
1 - Trunk ID ......... 1
2 - Trunk Name .......
3 - Trunk Method ..... SRC/DST MAC
4 - Trunk Ports ......
C - Create Trunk
R - Return to Previous Menu
Enter your selection?
