Chapter 8: Static and LACP Port Trunks
160 Section I: Basic Features
The Port Trunking and LACP menu is shown in Figure 42.
Figure 42. Port Trunking and LACP Menu
3. From the Port Trunking and LACP menu, type 1 to select Static Port
Trunking.
The Static Port Trunking menu is shown in Figure 43.
Figure 43. Static Port Trunking Menu
This menu lists the trunks that already exist on the switch. The
information includes the following:
ˆ ID - The ID number of the static port trunk.
ˆ Name - The name of the trunk.
ˆ Ports - The ports of the trunk.
ˆ Method - The load distribution method, which can be any one of
the following:
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Port Trunking and LACP
1 - Static Port Trunking
2 - LACP Configuration
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Static Port Trunking
ID Name Ports Method Status
----------------------------------------------------
C - Create Trunk
D - Delete Trunk
M - Modify Trunk
R - Return to Previous Menu
Enter your selection?
