Set Beeper
The Set Beeper Sub-Menu displays one System Setting, which is editable
Beeper enable: Yes (default)= Enables beeper No = Disables beeper (does NOT affect ladder
access)
Set Screen
The Set Screen Sub-Menu displays four System Settings, all of which are editable
Saver enable: Yes = Enable screen saver No (default) = Disable screen saver
Timeout(min): 5 - 1200 = Amount of time to expire with NO touch activity before activating screen
saver (black screen)
Popup Status: Off (default) = Disable popup status Warning = Display popup status only if
controller status changes to NOT Ok or NOT Run mode. ON
= Display popup status on any
controller status change
Update Time (mS): 2 - 50 = Maximum amount of time to allow for graphics update per scan
Removable Media
The Removable Media Sub-Menu displays the Removable Media Manager (see page 25). After
selecting Removable Media from the Main Menu, one of four Sub-Menu screens will appear:
= No Compact Flash card has been installed
in the Memory slot
= Compact Flash card is installed and
initialized, but contains no files
= Compact Flash card is installed and
initialized, and it contains files
Media Directory
FILENAM1.EXT 508 11-1-06 10:23a
Free bytes: 6382590
Total bytes: 63826944
Del
Del
All For
mat Save
Pgm
Esc
Media Directory
Media Card Not Present
Free bytes:
Total bytes:
Del
Del
All For
mat Save
Pgm
Esc
Media Directory
Directory Empty
Free bytes: 63826944
Total bytes: 63826944
Del
Del
All For
mat Save
Pgm
Esc
