2.3.3
Video Capture Option (VIM400)
The Video Capture Option (VIM400) permits you to integrate security, view machinery in remote
locations, or incorporate a machine vision monitor with the control system. The VIM400 allows four
channels of NTSC or PAL video to be connected to a QX OCS.
By using the Video Object in Cscape software, video can be displayed on OCS screens in various sizes.
The Video Object allows viewing video in a window, freezing the video, saving a single frame of the video
to Compact Flash, or viewing the video full screen with the full frame rate. A separate control register
allows ladder code to optionally freeze or save video snap-shots based on the machine’s state.
2.4
Product Specifications (QX and Back Pack)
Product Specifications are covered in the datasheet sent with the product in the box.
2.5
Required and Suggested Accessories
The following list contains a sampling of required and suggested QX accessories. Visit our website (see
page 92) to view updates on new products and accessories.
Note: The QX is not shipped with a programming cable in the box. To obtain a programming
cable, order HE500CBL300.
Table 2.2 – QX Accessories
Part Number Description
HE500OSW232
Cscape Software Package. Includes Cscape CD, 9-pin OCS Programming Cable, RJ-
45 Programming Cable, Documentation
HE500CBL300 OCS Programming Cable, 9-pin female (PC) to RJ-45 (OCS) - 6 feet.
