- 60-
Revision 4.6 3/2004
Enter Interval
sec. xxxxxx
Step 4 Using the number keys enter the desired time
interval in seconds. The interval may be from 0.1 sec-
onds to 65,000 seconds.
Enter Interval
sec. 600
The above example shows an interval of 600 seconds or
10 minutes.
Step 5 After the desired time interval is entered and
shown on the display press the enter key.
ENT
The HHC system will respond by displaying the follow-
ing:
Readings to Log
None Left Rght Both
Step 6 Using the arrow key select the desired Quick
Select Modules to be monitored.
Readings to Log
None Left Rght Both
In the above example the left module has been desig-
nated as the Quick Select Module to be monitored for
data logging.
Step 7 With the Quick Select module(s) to be moni-
tored selected and flashing press the EnT key.
ENT
After the Quick Select pressure module(s) to be moni-
tored has been entered the HHC system will respond by
displaying:
Date/Time Stamp
Disable Enable
Note: If data storage is done with the time/date stamp
option the HHC system can store 387 sets of pressure
measurements. Sets of pressure measurement data
include pressure measurement from the left, right or
both modules.
If data storage is done without the time/date stamp
option the HHC system can store 714 sets of pressure
measurements. Sets of pressure measurement data
include pressure measurement from the left, right or
both modules.
Step 8 Using the arrow keys select the desired stor-
age format. The desired format will flash on the display
when selected.
Date/Time Stamp
Disable Enable
In the above example the date time stamp function has
been enabled and the stored data will be labeled with
time date information in the database.
Step 9 With the desired format displayed press the
enter key.
ENT
After pressing the enter key immediately turn the HHC
system off.
When the event timer and data log functions are set up
as outlined in Section 25, the HHC system will automat-
ically turn itself on and make the programmed measure-
ments over the desired time interval. At the conclusion
of the programmed monitoring period the HHC system
will automatically turn itself off.
To review logged data or perform any other data log-
ging functions such as data labeling or uploading to a
personal computer see the main data logging section
(Section 22) of this manual.
Section 26.0 Alarm Function – Overview
(Optional Feature)
Important Note: This feature is not functional in FM
Approved Units. In order for the base unit to meet the re-
quirements of Class 1, Division 1, Groups A, B, C & D
hazardous areas it was necessary to disable this function.
The HHC can be equipped with a set of single pole
single throw (SPST) relays for use in triggering annun-
ciator lights, fans, sirens, etc. The relays have the fol-
lowing specifications:
Relay Specifications
Parameter Specification
Switch Arrangement: Form C
Resistance (max): 50 micro ohms
Switching Power (max): 30 W, 62.5 VA
(resistive load)
Switching Voltage (max): 110 V dc, 125 Vac
Switching Current (max): 1 Amp
Switching Capability (min): 10 micro amp, 10 mVdc
The relay contact closures are accessed through the 9
Pin female D connector on the right side of the HHC.
Pin out information for set point contacts is as follows
Pin 1 Relay 1 common
Pin 7 Relay 1 (normally open or normally closed)
