- 49 -
Revision 4.6 3/2004
Select pressure modules to be monitored and logged.
Readings to Log
None Left Rght Both
In this example we have opted to log the output from
both Quick Select pressure modules.
Step 8 With the Quick Select module(s) to be moni-
tored selected and flashing press the enter key.
ENT
The HHC system will respond by displaying:
Date/Time Stamp
Disable Enable
Note: If data storage is done with the time/date stamp
option activated, the HHC system can store 387 sets of
pressure measurements. If data storage is done without
the time/date stamp option activated the HHC system
can store 714 sets of pressure measurements. A data set
is the full package of information defining the logged
output from one module.
Using the arrow keys select the desired storage format.
The desired format will flash when selected.
Date/Time Stamp
Disable Enable
In this example we have opted to forego the date/time
stamp of the stored data values.
Step 9 With the desired format displayed press the
enter key.
ENT
The HHC system will immediately begin storing the
pressure data requested at the desired interval until
instructed to stop the data logging process.
Step 10 To stop the data logging process press the Data
Log key. The HHC system will respond by displaying:
Auto Manual
Review Off
Step 11 Using the arrow keys select the word off. When
selected the word “Off” will flash.
Auto Manual
Review Off
Step 12 With the word “Off” flashing press the enter
key to disable the data log function.
ENT
Automatic, time interval based, data logging has now
been terminated.
Section 22.5 Manual Data Logging – Standard
Data Logging Mode
Follow the procedure below to conduct manual, operator
controlled, data logging.
Step 1 With the HHC system on and reading pressure
press the data log key.
DATA
LOG
The HHC system will respond by displaying:
THE LAST DATA LOG MEnU SCREEn USED
Step 2 Using the up/down and right/left arrows browse
through the data log menu and locate the word “Manual.”
The menu line with the word “Manual” appears as:
Auto Manual
To initiate manual data logging select the word
“Manual” using the arrow keys. When selected the word
“Manual” will flash on the display.
Auto Manual
Step 3 With the word “Manual” flashing press the enter
key.
ENT
The HHC system will respond by displaying:
Readings to Log
None Left Rght Both
Step 4 Using the arrow key select the desired Quick
Select modules to be monitored.
Readings to Log
None Left Rght Both
In this example we have opted to log the output from
both Quick Select pressure modules.
Step 5 With the Quick Select module(s) to be monitored
and logged selected and flashing press the enter key.
ENT
The HHC system will respond by displaying:
Date/Time Stamp
Disable Enable
Note: If data storage is done with the time/date stamp
option activated the HHC system can store 387 sets of
pressure measurements. If data storage is done without
the time/date stamp option the HHC system can store
714 sets of pressure measurements. Sets of pressure
measurement data include all the data stored to define
the output of one module.Using the arrow keys select the
