- 55 -
Revision 4.6 3/2004
DATA
STORE
After the last set of data to be logged has been stored the
HHC will prompt the operator with the following display.
AsFound readings
View Done Redo
The options available are as follows:
View: Allows operator to scan through the stored values
using the arrow keys. Use the leftpointing arrow to move
in decreasing order from data point to data point. Use
the down-ward pointing arrow to move in decreasing
order 10 data points at a time. Use the right pointing
arrow to move in increasing order from data point to
data point. Use the upward pointing arrow to move in
increasing order 10 data points at a time.
Done: Completes the collection of “AsFound” measure-
ment data. See step 13 for continuation of the “CertGen”
process.
Redo: Provides the ability to discard all the “As Found”
data taken under the tag name being tested. Prior to
deleting the data the operator will be prompted by the
query.
ERASE all data
Yes No
Selecting yes will result in the deletion of the just taken
“as found data”.
Step 13 After selecting “Done” the HHC will offer the
opportunity to enter the ambient (environmental) tem-
perature at the time the calibration is being done. This is
accomplished by the display of the following.
Ambient Temperature
Skip Enter
To skip the act of logging the ambient temperature value
select the text “Skip” and press the enter key.
ENT
To “capture” the ambient temperature and make it part
of the calibration record use the arrow keys to select the
text “Enter”.
Ambient Temperature
Skip Enter
Step 14 To proceed with the entry/recording of the
ambient temperature value with the text “Entry” flashing
press the enter key.
ENT
Step 15
Note : If the HHC has an GQS-RT or TC temperature
module and the probe is installed it will automatically
offer the opportunity to store the measured tempera-
ture value.
If a different value is to be entered or if the HHC is not
equipped with a temperature module the temperature
can be entered via the numeral keys on the keypad. With
manual temperature entry completed the display will
look as follows
Enter Amb Temp o F
73.4
for an ambient temperature of 73.4 degrees Fahrenheit.
Step 16 With the desired temperature value displayed
press the enter key.
ENT
The HHC will respond by displaying:
Action Taken
None Recal Repl
Using the arrow keys select the desired course of action.
Select:
none: if no action is required and the device under test
is performing satisfactorily.
Recal: If adjustments are to be made to the device
under test.
Repl: If it has been determined that the tested device
must be taken off line and replaced.
The selected entry will become part of the stored
data for the calibration being done against the
previously entered tag name.
Step 17 With the desired selection highlighted press
the enter key.
ENT
The HHC will respond by displaying:
Collect As Left
Yes No AsFnd
Use the arrow keys to highlight the desired selection.
The
typical selections are:
Yes: If recalibration is selected as the action taken.
Proceed to Step 18 for details on taking “As
Left” data
no: If replace is selected as the action taken.
AsFnd: If no action is taken because the device under
test was found to be within specification.
Selecting “AsFnd “ will result in the following com-
