17 Annexe A - Tableau des adresses dip-switch
Ci-après, on reporte toutes les combinaisons possibles.
h Le levier du dip-switch vers le haut représente la valeur 1 (ON) tandis que le levier vers le bas
représente la valeur 0 (OFF).
SÉRIELS ET ADRESSE, CONFIGURATION ADRESSE
DIP 10 DIP 9 DIP 8 DIP 7 DIP 6 DIP 5 DIP 4 DIP 3 DIP 2 DIP 1 Configuration
- - OFF OFF OFF OFF OFF OFF OFF OFF Adresse non valide
- - OFF OFF OFF OFF OFF OFF OFF ON Adresse 1
- - OFF OFF OFF OFF OFF OFF ON OFF Adresse 2
- - OFF OFF OFF OFF OFF OFF ON ON Adresse 3
- - OFF OFF OFF OFF OFF ON OFF OFF Adresse 4
- - OFF OFF OFF OFF OFF ON OFF ON Adresse 5
- - OFF OFF OFF OFF OFF ON ON OFF Adresse 6
- - OFF OFF OFF OFF OFF ON ON ON Adresse 7
- - OFF OFF OFF OFF ON OFF OFF OFF Adresse 8
- - OFF OFF OFF OFF ON OFF OFF ON Adresse 9
- - OFF OFF OFF OFF ON OFF ON OFF Adresse 10
- - OFF OFF OFF OFF ON OFF ON ON Adresse 11
- - OFF OFF OFF OFF ON ON OFF OFF Adresse 12
- - OFF OFF OFF OFF ON ON OFF ON Adresse 13
- - OFF OFF OFF OFF ON ON ON OFF Adresse 14
- - OFF OFF OFF OFF ON ON ON ON Adresse 15
- - OFF OFF OFF ON OFF OFF OFF OFF Adresse 16
- - OFF OFF OFF ON OFF OFF OFF ON Adresse 17
- - OFF OFF OFF ON OFF OFF ON OFF Adresse 18
- - OFF OFF OFF ON OFF OFF ON ON Adresse 19
- - OFF OFF OFF ON OFF ON OFF OFF Adresse 20
- - OFF OFF OFF ON OFF ON OFF ON Adresse 21
- - OFF OFF OFF ON OFF ON ON OFF Adresse 22
- - OFF OFF OFF ON OFF ON ON ON Adresse 23
- - OFF OFF OFF ON ON OFF OFF OFF Adresse 24
- - OFF OFF OFF ON ON OFF OFF ON Adresse 25
- - OFF OFF OFF ON ON OFF ON OFF Adresse 26
- - OFF OFF OFF ON ON OFF ON ON Adresse 27
- - OFF OFF OFF ON ON ON OFF OFF Adresse 28
- - OFF OFF OFF ON ON ON OFF ON Adresse 29
- - OFF OFF OFF ON ON ON ON OFF Adresse 30
- - OFF OFF OFF ON ON ON ON ON Adresse 31
- - OFF OFF ON OFF OFF OFF OFF OFF Adresse 32
- - OFF OFF ON OFF OFF OFF OFF ON Adresse 33
- - OFF OFF ON OFF OFF OFF ON OFF Adresse 34
- - OFF OFF ON OFF OFF OFF ON ON Adresse 35
- - OFF OFF ON OFF OFF ON OFF OFF Adresse 36
- - OFF OFF ON OFF OFF ON OFF ON Adresse 37
- - OFF OFF ON OFF OFF ON ON OFF Adresse 38
- - OFF OFF ON OFF OFF ON ON ON Adresse 39
- - OFF OFF ON OFF ON OFF OFF OFF Adresse 40
- - OFF OFF ON OFF ON OFF OFF ON Adresse 41
