Triton Isis User Manual
Page 82
June 2004 Isis® Sonar User's Manual, Volume 2
72
• Set camera parameters
• Set the starting contact number
• Enable or disable speed correction
• Establish RAMP support
• Specify the shape and type of pointer (cursor) to use
• Enable or disable startup with min/max
Table E-3 below explains the options in the Edit menu.
Table E-3. Edit menu choices
Task Choice
Meaning or Action Performed
Copy to Clipboard
Copies an image of your currently selected target to
the Windows Clipboard
Annotate… [F2]
Displays a text box where you can add a note to
describe or otherwise identify a contact description:
Figure E-5. Annotation dialog box
Appendix E: Using the Target Utility
