June 2004 Isis® Sonar User's Manual, Volume 2 19
description.
Channel 3 Sonar Parameters and Range to Fish
0136 ch3_floatRawRange 4 FLOAT Higher resolution raw maximum
slant range in meters. Used in
DSP and Isis; not Q-MIPS.
0140 ch3_delayRange 4 FLOAT Channel delay in meters,
entered in Q-MIPS DIGITIZER
menu in seconds and converted
to meters.
0144 ch3_bandWidth 2 USHORT Sonar channel bandwidth in
kHz. *
0146 ch3_sampleScheme 2 USHORT [1...5] See ch1_sampleScheme
description.
0148 ch3_rawRange 2 USHORT See ch1_rawRange description.
0150 ch3_initialGain 1 BYTE Initial channel gain. †*
0151 ch3_gain 1 BYTE Channel gain. †*
0152 range_to_fish 2 USHORT Distance to fish in meters
multiplied by 10.*
0154 ch3_signalDivisor 2 USHORT Signal divisor multiplied by 100,
see under Digitizer Parameters
ch1_signalDivisor.
0156 ch3_correctedRange 2 USHORT See ch1_correctedRange
description
Channel 4 Sonar Parameters and Bearing to Fish
0158 ch4_floatRawRange 4 FLOAT Higher resolution raw maximum
slant range in meters. Used in
DSP and Isis; not Q-MIPS.
Appendix A: Q-MIPS File Format
