June 2004 Isis® Sonar User's Manual, Volume 2
150
Automatically open
Bathymetry
Confidence Window
Put a check mark in this option to enable it. When enabled, an
independent, non-docked window is displayed during your recording
session to quantify the water depth being reported by a beam number
you specify. This gives you a way of monitoring and comparing the
actual water depth as being reported simultaneously by a single-beam
and multibeam sonar system. Figure I-11 shows such a window where
the parameters (
Beam no. and Bias) have not yet been specified.
Bias refers to the user-specified offset of the two sonar systems.
Figure I-11. Bathymetry Confidence Check window
Appendix I: Working with Specific Sonars
