June 2004 Isis® Sonar User's Manual, Volume 2
101
NewPositionX 456 DOUBLE Corrected position computed
with the measure function
ComputedLength 464 DOUBLE Along track
ComputedWidth 472 DOUBLE Across track
ComputedHeight 480 DOUBLE Computed height of object
above the seabed
ComputedDepth 488 DOUBLE Depth computed from latitude
and pressure
ComputedMooredAltitude 496 DOUBLE Altitude of object from bottom
NumPingsOnContact 504 WORD Total pings for contact
ContactIndex 506 DWORD Index into the contacts.bin file
ExpandFactor 510 SHORT How much to enlarge the image
in a multiple document interface
window
ExpandCenterX 512 WORD Center of the expand X
ExpandCenterY 514 WORD Center of the expand Y
AssignedPositionX 516 DOUBLE Assigned position used to set
contact pos from RovFlite
AssignedPositionY 524 DOUBLE Assigned position used to set
contact pos from RovFlite
KP 532 FLOAT Kilometers of pipe
wBitsPerPixel 538 WORD How many bits (8 or 16)?
LastClickPoint 542 WPOINT Preserves where the user last
clicked for updating the Cursor
section of the info dialog box
CorrectedChannelFlags 546 DWORD If bit 0 is set to 1, channel 0 has
already been slant-range
corrected.
ChannelBoundaryOffset 548 WORD Used to track a bitmap crossing
a channel boundary
RampFileUsed 550 WORD 0 = not used; 1 = fish; 2 = ship
ContactType 552 WORD 0 = normal sonar image; 1 =
polygon points; 2 = ESC image
DisplayUnits 554 WORD 0 = meters; 1 = feet; 2 =
milliseconds
TimeOffTrack 562 DOUBLE Seconds, time off track to the
contact
Appendix E: Using the Target Utility
