June 2004 Isis® Sonar User's Manual, Volume 2
18
0110
sampleRate
2
USHORT Aggregate sample rate in kHz,
set by user in Q-MIPS record
mode setup. Not used in Isis.
0112 ch1_correctedRang
e
2
USHORT Single-side range of corrected
channel in meters, zero if
corrected data are not saved. On
any asynchronous channel, this
holds the async delay in meters
multiplied by 100. Not currently
used in Isis.
Channel 2 Sonar Parameters
0114
ch2_floatRawRange
4
FLOAT
Higher resolution raw maximum
slant range in meters. Used in
DSP and Isis; not Q-MIPS.
0118
ch2_delayRange
4
FLOAT
Channel delay in meters,
entered in Q-MIPS DIGITIZER
menu in seconds and converted
to meters. Not used in Isis.
0122
ch2_bandWidth
2
USHORT Sonar channel bandwidth in
kHz. Not used in Isis. *
0124
ch2_sampleScheme
2
USHORT [1...5] See ch1_sampleScheme
description.
0126
ch2_rawRange
2
USHORT See ch1_rawRange description.
†
0128
ch2_initialGain
1
BYTE
Initial channel gain. †*
0129
ch2_gain
1
BYTE
Channel gain. †*
0130
oceanTide
2
USHORT Altitude above Geoide (from
RTK)
0132
ch2_signalDivisor
2
USHORT Signal divisor multiplied by 100,
see under Digitizer Parameters
ch1_signalDivisor.
0134 ch2_correctedRange
2 USHORT See
ch1_correctedRange
description
Appendix A: Q-MIPS File Format
