June 2004 Isis® Sonar User's Manual, Volume 2
11
0058
navSystemName
100BYTE
Not currently used, all null
chars (0). Prior to version
6.00, set to
SERIAL_INPUT for serial
port nav. Could also be
QUILS II, SONARDYNE, or
NOTHING in older
versions.
0158
projectionType
12 BYTE
Not currently used, all null
chars (0).
0170
spheriodType
2 BYTE
Not currently used, all null
chars (0).
0182
zone
2 USHORT Not used, all zeros (was
UTM zone).
0184
originLat
4 FLOAT
Origin of the local
coordinate system in
decimal degrees for
conversion from nav
system.
0188 originLong
4
FLOAT
0192 offsetLat
4
FLOAT
0196 offsetLong
4
FLOAT
northings and eastings to
Latitude and Longitude; not
currently used, all zeros.
Offset of the local
coordinate system in
meters from origin; not
currently used; all zeros.
0200
navUnits
2 USHORT [0...3], units for nav data, 0:
meters, 1: feet, 2: yards, 3:
degrees (Latitude &
Longitude); feet and yards
are not currently used.
Site Parameters
0202 diveNumber
2
USHORT
0204 blockNumber
2
USHORT
0206 trackNumber
2
USHORT
All fields in this section are
currently not in use. They
ll
t t 0
Appendix A: Q-MIPS File Format
