27
PARAMETER VALUE CHART Programmer ________________ Date ________
PAXDR Model Number _________ Meter# _____________ Security Code __________
 Rate Setup Parameters
DISPLAY PARAMETER
FACTORY
SETTING
USER
SETTING
 LOW UPDATE TIME 
 HIGH UPDATE TIME 
 RATE C CALCULATION 
 RATE C DISPLAY MULTIPLIER** 
 RATE C DECIMAL POSITION** 
 RATE C DISPLAY INDICATOR** 
 RATE A & B DECIMAL POSITION** 
 RATE A DECIMAL POSITION*** 
 RATE A LINEARIZER SEGMENTS 
 A SCALING PT 1 - DISPLAY VALUE 
 A SCALING PT 1 - INPUT VALUE 
 A SCALING PT 2 - DISPLAY VALUE 
 A SCALING PT 2 - INPUT VALUE 
 A SCALING PT 3 - DISPLAY VALUE 
 A SCALING PT 3 - INPUT VALUE 
 A SCALING PT 4 - DISPLAY VALUE 
 A SCALING PT 4 - INPUT VALUE 
 A SCALING PT 5 - DISPLAY VALUE 
 A SCALING PT 5 - INPUT VALUE 
 A SCALING PT 6 - DISPLAY VALUE 
 A SCALING PT 6 - INPUT VALUE 
 A SCALING PT 7 - DISPLAY VALUE 
 A SCALING PT 7 - INPUT VALUE 
 A SCALING PT 8 - DISPLAY VALUE 
 A SCALING PT 8 - INPUT VALUE 
 A SCALING PT 9 - DISPLAY VALUE 
 A SCALING PT 9 - INPUT VALUE 
 A SCALING PT 10 - DISPLAY VALUE 
 A SCALING PT 10 - INPUT VALUE 
 RATE A DISPLAY ROUNDING 
 RATE B DECIMAL POSITION*** 
 RATE B LINEARIZER SEGMENTS 
 B SCALING PT 1 - DISPLAY VALUE 
 B SCALING PT 1 - INPUT VALUE 
 B SCALING PT 2 - DISPLAY VALUE 
 B SCALING PT 2 - INPUT VALUE 
 B SCALING PT 3 - DISPLAY VALUE 
 B SCALING PT 3 - INPUT VALUE 
 B SCALING PT 4 - DISPLAY VALUE 
 B SCALING PT 4 - INPUT VALUE 
 B SCALING PT 5 - DISPLAY VALUE 
 B SCALING PT 5 - INPUT VALUE 
 B SCALING PT 6 - DISPLAY VALUE 
 B SCALING PT 6 - INPUT VALUE 
 B SCALING PT 7 - DISPLAY VALUE 
 B SCALING PT 7 - INPUT VALUE 
 B SCALING PT 8 - DISPLAY VALUE 
 B SCALING PT 8 - INPUT VALUE 
 B SCALING PT 9 - DISPLAY VALUE 
 B SCALING PT 9 - INPUT VALUE 
 B SCALING PT 10 - DISPLAY VALUE 
 B SCALING PT 10 - INPUT VALUE 
 RATE B DISPLAY ROUNDING 
** Parameter only appears when RATE C is enabled.
*** Parameter only appears when RATE C is disabled.
 User Input and Function Key Parameters
DISPLAY PARAMETER
FACTORY
SETTING
USER SETTING
 USER INPUT 1 
 USER INPUT 2 
 USER INPUT 3 
 FUNCTION KEY 1 
 FUNCTION KEY 2 
 RESET KEY 
 SECOND FUNCTION KEY 1 
 SECOND FUNCTION KEY 2 
 Display and Program Lock-out Parameters
DISPLAY PARAMETER
FACTORY
SETTING
USER SETTING
 RATE A DISPLAY LOCK-OUT 
 RATE B DISPLAY LOCK-OUT 
 RATE C DISPLAY LOCK-OUT 
 TOTALIZER A DISPLAY LOCK-OUT 
 TOTALIZER B DISPLAY LOCK-OUT 
 TOTALIZER C DISPLAY LOCK-OUT 
 SETPOINT 1 ACCESS LOCK-OUT 
 SETPOINT 2 ACCESS LOCK-OUT 
 SETPOINT 3 ACCESS LOCK-OUT 
 SETPOINT 4 ACCESS LOCK-OUT 
 TOTALIZER A COUNT LOAD ACCESS 
 TOTALIZER B COUNT LOAD ACCESS 
 TOTAL A SCALE FACTOR ACCESS 
 TOTAL B SCALE FACTOR ACCESS 
 TOTAL C SCALE FACTOR ACCESS 
 SECURITY CODE 
 Totalizer A and B Setup Parameters
DISPLAY PARAMETER
FACTORY
SETTING
USER SETTING
 TOTALIZER A OPERATING MODE 
 TOTALIZER A RESET ACTION 
 TOTALIZER A DECIMAL POSITION 
 TOTALIZER A SCALE FACTOR (A) 
TOTALIZER A SCALE FACTOR (B)* 
 TOTALIZER A SCALE MULTIPLIER 
 TOTALIZER A COUNT LOAD (A) 
TOTALIZER A COUNT LOAD (B)* 
 TOTALIZER A RESET AT POWER-UP 
 TOTALIZER B OPERATING MODE 
 TOTALIZER B RESET ACTION 
 **** TOTALIZER B DECIMAL POSITION 
 TOTALIZER B SCALE FACTOR (A) 
TOTALIZER B SCALE FACTOR (B)* 
 TOTALIZER B SCALE MULTIPLIER 
 TOTALIZER B COUNT LOAD (A) 
TOTALIZER B COUNT LOAD (B)* 
 TOTALIZER B RESET AT POWER-UP 
* See Module 2, Exchanging Parameter Lists, for details on programming this value.
**** Parameter only appears when Totalizer C is disabled.
