Page 18
18
18
Totalizer C
Decimal
Position
Totalizer C
Scale Factor
Totalizer C
Scale
Multiplier
Totalizer C
Reset at
Power-up
C tot
Totalizer C
Calculation
PAR
5-totC
CdECPt
CSCALr
C P-UP
Pro
CSCFAC
PARAMETER MENU
TOTALIZER C CALCULATION
TOTALIZER C DECIMAL POSITION
This selects the decimal point position for Totalizer C and any setpoint value
assigned to Totalizer C. The selection will also affect Totalizer C scale factor
calculations.
TOTALIZER C SCALE FACTOR
The result of the Totalizer C calculation is multiplied by the Scale Factor and
Scale Multiplier to obtain the Totalizer C display value. Normally, a scale factor
of 1.00000 is used to show the calculated result without any further scaling
applied. If however, additional scaling is needed, the scale factor can be set to
provide the desired reading.
to
Module 5 is the programming for Totalizer C. For maximum input frequency,
the Totalizer C Calculation should be set to
when not in use. When set to
,
the remaining Totalizer C parameters are not accessible. The C
annunciator indicates that Totalizer C is being shown in the Display Mode. An
Exchange Parameter List feature for the Scale Factor is explained in Module 2.
Select the calculation for Totalizer C display.
SELECTION
ACTION
No Calculation. Totalizer C disabled.
TOTALIZER A - Totalizer C shows Totalizer A with additional
scaling applied per the Totalizer C scaling parameters.
SUM (A+B). Totalizer C shows the sum of Totalizer A and
Totalizer B.
DIFFERENCE (A-B). Totalizer C shows the difference of Totalizer
A and Totalizer B.
RATIO (A/B). Totalizer C shows the percentage of Totalizer A to
Totalizer B.
PERCENT OF TOTAL (A/A+B). Totalizer C shows the percentage
of Totalizer A to the sum of Totalizer A and Totalizer B.
6.5 MODULE 5 - T
OTALIZER
C S
ETUP
P
ARAMETERS
(
)
TOTALIZER C SCALE MULTIPLIER
Set the Scale Multiplier to provide the desired Totalizer C display resolution.
For Totalizer C percentage calculations, the result is internally multiplied by
10,000 to show percentage in hundredths with a scale multiplier of 1 (select 2
decimal places). By using a scale multiplier of 0.1 or 0.01, along with the proper
decimal point position, the display can be divided down to show percentage in
tenths or in whole numbers respectively.
TOTALIZER C RESET AT POWER-UP
Totalizer C may be programmed to reset at each meter power-up.
