HMP228
M210282en-A
Operating Manual
43
5.7
Electromagnetic compatibility
The emission and immunity tests have been performed according to
thestandard EN61326-1:1997+Am1:1998; Industrial environment.
5.7.1
Emissions
Test:
Setup according to:
Radiated emissions
EN 55022/CISPR 22 (class B)
With power supply unit (HMP230PW):
Conducted emissions
EN 55022/CISPR 22 (class B)
Harmonic currents
EN/ IEC 61000-3-2
Voltage fluctuations
EN/ IEC 61000-3-3
5.7.2
Immunity
Test:
Setup according to:
Electrostatic discharge
EN/ IEC 61000-4-2
Electrical fast transients
EN/ IEC 61000-4-4
Radiated immunity
EN/ IEC 61000-4-3
Conducted immunity
EN/ IEC 61000-4-6
Voltage proof, AC: DC supply (+ or -) to housing 250 VAC, 1 minute (300 k
Ω
and 15 nF parallel)
